Queued Analog-to-Digital Converter (QADC)
Freescale Semiconductor
28-27
28.6.8
Result Registers
The result word table is a 64 half-word (128 byte) long by 10-bit wide RAM. An entry is written by the
QADC after completing an analog conversion specified by the corresponding CCW table entry.
28.6.8.1
Right-Justified Unsigned Result Register (RJURR)
28.6.8.2
Left-Justified Signed Result Register (LJSRR)
1
All channels not listed are reserved or unimplemented and return undefined results.
15
10
9
8
Field
—
RESULT
Reset
0000_00
Undefined
R/W:
R
R/W
7
0
Field
RESULT
Reset
Undefined
R/W:
R/W
Address
IPSBAR + 0x19_0280, 0x19_02fe
Figure 28-15. Right-Justified Unsigned Result Register (RJURR)
Table 28-18. RJURR Field Descriptions
Bit(s)
Name
Description
15–10
—
Reserved, should be cleared.
9–0
RESULT
The conversion result is unsigned, right-justified data.
15
14
8
Field
S
RESULT
Reset
Undefined
R/W:
R/W
7
0
Field
RESULT
Reset
Undefined
R/W:
R/W
Address
IPSBAR + 0x19_0300, 0x19_037e
Figure 28-16. Left-Justified Signed Result Register (LJSRR)
MCF5282 and MCF5216 ColdFire Microcontroller User’s Manual, Rev. 3
