Debug Support
Freescale Semiconductor
30-19
.
describes receive BDM packet fields.
30.5.2.2
Transmit Packet Format
, consists of 16 data bits and 1 control bit.
describes transmit BDM packet fields.
30.5.3
BDM Command Set
summarizes the BDM command set. Subsequent paragraphs contain detailed descriptions of
each command. Issuing a BDM command when the processor is accessing debug module registers using
the WDEBUG instruction causes undefined behavior.
16
15
0
S
Data Field [15:0]
Figure 30-13. Receive BDM Packet
Table 30-15. Receive BDM Packet Field Description
Bits
Name
Description
16
S
Status. Indicates the status of CPU-generated messages listed below. The not-ready response can be
ignored unless a memory-referencing cycle is in progress. Otherwise, the debug module can accept a
new serial transfer after 32 processor clock periods.
S DataMessage
0 xxxxValid data transfer
0 0xFFFFStatus OK
1 0x0000Not ready with response; come again
1 0x0001Error—Terminated bus cycle; data invalid
1 0xFFFFIllegal command
15–0
D
Data. Contains the message to be sent from the debug module to the development system. The
response message is always a single word, with the data field encoded as shown above.
16
15
0
C
D
Figure 30-14. Transmit BDM Packet
Table 30-16. Transmit BDM Packet Field Description
Bits
Name
Description
16
C
Control. This bit is reserved. Command and data transfers initiated by the development system should
clear C.
15–0
D
Data bits 15–0. Contains the data to be sent from the development system to the debug module.
MCF5282 and MCF5216 ColdFire Microcontroller User’s Manual, Rev. 3
