Shown in, Figure 16-8, Table 16-3 describes dcr n fields – Motorola ColdFire MCF5281 User Manual
Page 304

DMA Controller Module
16-8
Freescale Semiconductor
describes DCRn fields.
31
30
29
28
27
25
24
23
22
21
20
19
18
17
16
Field INT
EEXT
CS
AA
BWC
—
—
SINC
SSIZE
DINC
DSIZE
START
Reset
0000_0000_0000_0000
R/W
R/W
15
14
0
Field AT
1
1
Available only if BCR24BIT = 1, otherwise reserved.
—
Reset
0
N/A
R/W
R/W
Address
IPSBAR + 0x108, 0x148, 0x188, 0x1C8
Figure 16-8. DMA Control Registers (DCRn)
Table 16-3. DCRn Field Descriptions
Bits
Name
Description
31
INT
Interrupt on completion of transfer. Determines whether an interrupt is generated by completing a
transfer or by the occurrence of an error condition.
0 No interrupt is generated.
1 Internal interrupt signal is enabled.
30
EEXT
Enable external request. Care should be taken because a collision can occur between the START bit
and DREQ when EEXT = 1.
0 External request is ignored.
1 Enables external request to initiate transfer. The internal request (initiated by setting the START
bit) is always enabled.
29
CS
Cycle steal.
0 DMA continuously makes read/write transfers until the BCR decrements to 0.
1 Forces a single read/write transfer per request. The request may be internal by setting the START
bit, or external by asserting DREQ.
28
AA
Auto-align. AA and SIZE determine whether the source or destination is auto-aligned, that is,
transfers are optimized based on the address and size. See
Section 16.5.4.1, “Auto-Alignment
.”
0 Auto-align disabled
1 If SSIZE indicates a transfer no smaller than DSIZE, source accesses are auto-aligned; otherwise,
destination accesses are auto-aligned. Source alignment takes precedence over destination
alignment. If auto-alignment is enabled, the appropriate address register increments, regardless
of DINC or SINC.
