Interrupt Controller Modules
10-8
Freescale Semiconductor
.
.
31
16
Field
INT_MASK[63:48]
Reset
1111_1111_1111_1111
R/W
R/W
15
0
Field
INT_MASK[47:32]
Reset
1111_1111_1111_1111
R/W
R/W
IPSBAR + 0xC08, 0xD08
Figure 10-3. Interrupt Mask Register High (IMRHn)
Table 10-6. IMRHn Field Descriptions
Bits
Name
Description
31–0
INT_MASK
Interrupt mask. Each bit corresponds to an interrupt source. The corresponding IMRHn bit
determines whether an interrupt condition can generate an interrupt. The corresponding
IPRHn bit reflects the state of the interrupt signal even if the corresponding IMRHn bit is
set.
0 The corresponding interrupt source is not masked
1 The corresponding interrupt source is masked
31
16
Field
INT_MASK[31:16]
Reset
1111_1111_1111_1111
R/W
R/W
15
1
0
Field
INT_MASK[16:1]
MASKALL
Reset
1111_1111_1111_1111
R/W
R/W
IPSBAR + 0xC0C, 0xD0C
Figure 10-4. Interrupt Mask Register Low (IMRLn)
