Port B/C/D Pin Assignment Register (PBCDPAR)
The PBCDPAR controls the pin function of ports B, C, and D.
The PBCDPAR register is read/write.
7
6
5
0
Field
PBPA
PCDPA
—
Reset See Note 1
1
1
Reset state determined during reset configuration as shown in
See Note 1
00_0000
R/W:
R/W
R/W
R
Address
IPSBAR + 0x10_0050
Figure 26-19. Port B/C/D Pin Assignment Register (PBCDPAR)
Table 26-7. PBCDPAR Field Descriptions
Bits
Name
Description
7
PBPA
Port B pin assignment. Configures the port B pins for their primary
function (D[23:16]) or digital I/O.
1 Port B pins configured for primary function (D[23:16])
0 Port B pins configured for digital I/O
6
PCDPA
Ports C,D pin assignment. Configures the port C and D pins for their
primary functions (D[15:8], D[7:0]) or digital I/O.
1 Port C,D pins configured for primary function (D[15:8], D[7:0])
0 Port C,D pins configured for digital I/O
5–0
—
Reserved, should be cleared.
Table 26-8. Reset Values for PBCDPAR Bits
Mode of
Operation
Port Size of
External Boot
Device
1
1
Note if the port size of the external boot device is less than the port size
of the external SDRAM, the PBCDPAR register must be written after reset
to enable the primary function(s) on ports B,C, and D, before any SDRAM
accesses are attempted.
PBPA Reset
Value
PCDPA Reset
Value
Master mode
8-bit
0
0
16-bit
1
0
32-bit
1
1
Single chip mode
N/A
0
0
