SOFTRST
Soft reset. When this bit is asserted, the FlexCAN resets its internal state machines (sequencer,
error counters, error flags, and timer) and the host interface registers (CANMCR, CANICR,
CANTCR, IMASK, and IFLAG).
The configuration registers that control the interface with the CAN bus are not changed (CAN-
CTRL[0:2] and PRESDIV). Message buffers and receive message masks are also not changed.
This allows SOFTRST to be used as a debug feature while the system is running.
Setting SOFTRST also clears the STOP bit in CANMCR.
After setting SOFTRST, allow one complete bus cycle to elapse for the internal FlexCAN circuitry
to completely reset before executing another access to CANMCR.
The FlexCAN clears this bit once the internal reset cycle is completed.
0 Soft reset cycle completed
1 Soft reset cycle initiated
8
FRZACK
FlexCAN disable. When the FlexCAN enters debug mode, it sets the FRZACK bit. This bit should
be polled to determine if the FlexCAN has entered debug mode. When debug mode is exited, this
bit is negated once the FlexCAN prescaler is enabled. This is a read-only bit.
0 The FlexCAN has exited debug mode and the prescaler is enabled.
1 The FlexCAN has entered debug mode, and the prescaler is disabled.
7
SUPV
Supervisor/user data space. The SUPV bit places the FlexCAN registers in either supervisor or
user data space.
0 Registers with access controlled by the SUPV bit are accessible in either user or supervisor
privilege mode.
1 Registers with access controlled by the SUPV bit are restricted to supervisor mode.
6
SELF-
WAKE
Self wake enable. This bit allows the FlexCAN to wake up when bus activity is detected after the
STOP bit is set. If this bit is set when the FlexCAN enters low-power stop mode, the FlexCAN will
monitor the bus for a recessive to dominant transition. If a recessive to dominant transition is
detected, the FlexCAN immediately clears the STOP bit and restarts its clocks.
If a write to CANMCR with SELFWAKE set occurs at the same time a recessive-to-dominant edge
appears on the CAN bus, the bit will not be set, and the module clocks will not stop. The user
should verify that this bit has been set by reading CANMCR. Refer to
“Low-Power Stop Mode for Power Saving
” for more information on entry into and exit from
low-power stop mode.
0 Self wake disabled.
1 Self wake enabled.
5
APS
Auto-power save. The APS bit allows the FlexCAN to automatically shut off its clocks to save
power when it has no process to execute, and to automatically restart these clocks when it has a
task to execute without any CPU intervention.
0 Auto-power save mode disabled; clocks run normally.
1 Auto-power save mode enabled; clocks stop and restart as needed.
4
STOPACK
Stop acknowledge. When the FlexCAN is placed in low-power stop mode and shuts down its
clocks, it sets the STOPACK bit. This bit should be polled to determine if the FlexCAN has entered
low-power stop mode. When the FlexCAN exits low-power stop mode, the STOPACK bit is
cleared once the FlexCAN’s clocks are running.
0 The FlexCAN is not in low-power stop mode and its clocks are running.
1 The FlexCAN has entered low-power stop mode and its clocks are stopped
3–0
—
Reserved, should be cleared.
