16.4.5
DMA Status Registers (DSR0–DSR3)
In response to an event, the DMA controller writes to the appropriate DSRn bit,
. Only a write
to DSRn[DONE] results in action.
describes DSRn fields.
15
AT
AT is available only if MPARK[BCR24BIT] = 1.
DMA acknowledge type. Controls whether acknowledge information is provided for the entire transfer
or only the final transfer.
0 Entire transfer. DMA acknowledge information is displayed anytime the channel is selected as the
result of an external request.
1 Final transfer (when BCR reaches zero). For dual-address transfer, the acknowledge information
is displayed for both the read and write cycles.
14–0
—
Reserved, should be cleared.
7
6
5
4
3
2
1
0
Field
—
CE
BES
BED
—
REQ
BSY
DONE
Reset
0000_0000
R/W
R/W
Address
IPSBAR + 0x110, 0x150, 0x190, 0x1D0
Figure 16-9. DMA Status Registers (DSRn)
Table 16-4. DSRn Field Descriptions
Bits
Name
Description
7
—
Reserved, should be cleared.
6
CE
Configuration error. Occurs when BCR, SAR, or DAR does not match the requested transfer size,
or if BCR = 0 when the DMA receives a start condition. CE is cleared at hardware reset or by writing
a 1 to DSR[DONE].
0 No configuration error exists.
1 A configuration error has occurred.
5
BES
Bus error on source
0 No bus error occurred.
1 The DMA channel terminated with a bus error during the read portion of a transfer.
4
BED
Bus error on destination
0 No bus error occurred.
1 The DMA channel terminated with a bus error during the write portion of a transfer.
3
—
Reserved, should be cleared.
2
REQ
Request
0 No request is pending or the channel is currently active. Cleared when the channel is selected.
1 The DMA channel has a transfer remaining and the channel is not selected.
Table 16-3. DCRn Field Descriptions (continued)
Bits
Name
Description
