Read/write bus timings listed in Table 33-15 are shown in Figure 33-3 , Figure 33-4 , and Figure 33-5 .
B8 CLKOUT high to address (A[23:0]) and control (TS,
SIZ[1:0], TIP, R/W) valid t
CHAV
— 10 ns
B9 CLKOUT high to address (A[23:0]) and control (TS,
SIZ[1:0], TIP, R/W) invalid t
CHAI
2 — ns
Data Outputs
B11 CLKOUT high to data output (D[31:0]) valid t
CHDOV
— 10 ns
B12 CLKOUT high to data output (D[31:0]) invalid t
CHDOI
2 — ns
B13 CLKOUT high to data output (D[31:0]) high impedance t
CHDOZ
— 6 ns
1
CSn transitions after the falling edge of CLKOUT.
2
BS transitions after the falling edge of CLKOUT.
3
OE transitions after the falling edge of CLKOUT.
Table 33-15. External Bus Output Timing Specifications (continued)
Name Characteristic Symbol Min Max Unit
