Fast Ethernet Controller (FEC)
Freescale Semiconductor 17-33
The 7-wire serial mode interface (RCR[MII_MODE] cleared) is generally referred to as AMD mode.
Table 17-36 shows the 7-wire mode connections to the external transceiver.
17.5.7 FEC Frame Transmission
The Ethernet transmitter is designed to work with almost no intervention from software. After
ECR[ETHER_EN] is set and data appears in the transmit FIFO, the Ethernet MAC can transmit onto the
network. The Ethernet controller transmits bytes least significant bit (lsb) first.
When the transmit FIFO fills to the watermark (defined by TFWR), MAC transmit logic asserts
FEC_TXEN and starts transmitting the preamble (PA) sequence, the start frame delimiter (SFD), and then
the frame information from the FIFO. However, the controller defers the transmission if the network is
busy (FEC_CRS is asserted). Before transmitting, the controller waits for carrier sense to become inactive,
then determines if carrier sense stays inactive for 60 bit times. If so, transmission begins after waiting an
additional 36 bit times (96 bit times after carrier sense originally became inactive). See
Section 17.5.15.1,
“Transmission Errors,” for more details.
Collision FEC_COL
Carrier Sense FEC_CRS
Receive Clock FEC_RXCLK
Receive Data Valid FEC_RXDV
Receive Data FEC_RXD[3:0]
Receive Error FEC_RXER
Management Data Clock FEC_MDC
Management Data
Input/Output
FEC_MDIO
Table 17-36. 7-Wire Mode Configuration
Signal description EMAC Pin
Transmit Clock
FEC_ TXCLK
Transmit Enable
FEC_ TXEN
Transmit Data
FEC_ TXD[0]
Collision
FEC_ COL
Receive Clock
FEC_ RXCLK
Receive Data Valid
FEC_ RXDV
Receive Data
FEC_ RXD[0]
Table 17-35. MII Mode (continued)
Signal Description EMAC pin
