340
DHCPREQUEST Number of DHCPREQUEST packets
DHCPDECLINE Number of DHCPDECLINE packets
DHCPRELEASE Number of DHCPRELEASE packets
DHCPINFORM Number of DHCPINFORM packets
Message Send Statistics for DHCP packets sent
BOOTREPLY Total packets sent
DHCPOFFER Number of DHCPOFFER packets
DHCPACK Number of DHCPACK packets
DHCPNAK Number of DHCPNAK packets
DHCPRELAY Number of DHCPRELAY packets
DHCPFORWARD Number of DHCPFORWARD packets
10.6 Web Management
Click DHCP configuration. Users can configure DHCP on the switch.
10.6.1 DHCP server configuration
Click DHCP configuration, DHCP server configuration, The DHCP server
configuration page is shown.
10.6.1.1 Enable DHCP
Click DHCP configuration, DHCP server configuration, Enable DHCP. Users can
enable or disable DHCP server, and configure logging server:
DHCP server status -Enable or disable DHCP server. 0.0.1; set Logging server
port to 45, and then click Apply. The configuration is applied on the switch.
10.6.1.2 Address pool configuration
Click DHCP configuration, DHCP server configuration, Address pool configuration.
Users can configure DHCP address pool:
DHCP pool name (1-32 character) - Configure DHCP pool name. ; for
Address range for allocating, set IP address to 10.1.128.0; set Network mask to
255.255.255.0; set DHCP client node type to broadcast node; set Address lease timeout
to 3 day 12 hour 30 minute, and then click Apply. The configuration is applied on the
switch.
