Example: open the TFTP server, input the username “switch” and password “switch”, and
then click “Apply.”
2.10.4 Monitor And Debug Command
Users should click “Switch basic configuration” and “Basic configuration debug” to enter
into the configuration page and make configuration nodes, which include the following
segments:
z
Debug command-a debugging command.
z
Show calendar-to display the current time.
z
Dir to display FLASH files.
z
Show history-to display the latest inputted commands.
z
Show running-config-to display the current status of parameters configuration.
z
Show switch port interface-to display properties of VLAN ports.
z
Show tcp-to display the current TCP connection with the switch.
z
Show udp-to display the current UDP connection with the switch.
z
Show telnet login-to display the Telnet client messages connected through Telnet
with the switch.
z
Show telnet user-to display all Telnet client messages with authenticated switch
access through Telnet.
z
Show version-to display the number/version of the switch.
2.10.4.1 Debug command
User should click “Switch basic configuration”, “Basic configuration debug”, and “Debug
command” to enter into the configuration page and make configuration nodes, which
include “ping” and “traceroute” segments.
Words and phrases of “Ping” segment are explained in the following:
IP address-the destination IP address
Hostname-the name of the host Words and phrases of “IP Traceroute” segment are
explained in the following:
IP address-the destination IP address
Hostname-the name of the host
Hops-the maximum passing hops
Timeout- the timeout of data packets
