APPENDIX A MIPS III INSTRUCTION SET DETAILS
564
Preliminary User’s Manual S15543EJ1V0UM
SWL
Store Word Left (3/3)
SWL
Given a doubleword in a register and a doubleword in memory, the operation of SWL is as follows:
B
C
D
E
F
G
A
H
J
K
L
M
N
O
I
P
Register
Memory
SWL
vAddr2..0
Destination
Type
Offset
(LEM)
0
1
2
3
4
5
6
7
I J K L MN O E
I J K L MN E F
I J K L M E F G
I J K L E F G H
I J K E MN O P
I J E F MN O P
I E F GMN O P
E F G H MN O P
0
1
2
3
0
1
2
3
0
0
0
0
4
4
4
4
Remark
LEM
Little-endian memory (BigEndianMem = 0)
Type
AccessType (see Table 2-3. Byte Specification Related to Load and Store Instructions)
sent to memory
Offset
pAddr2..0 sent to memory
Exceptions:
TLB refill exception
TLB invalid exception
TLB modification exception
Bus error exception
Address error exception
