CHAPTER 1 INTRODUCTION
40 Preliminary User’s Manual S15543EJ1V0UM
(2/2)
Pin Name Pin No. I/O Active Level Function
SMD11 R5 I/O Memory data
SMD12 R2 I/O Memory data
SMD13 P1 I/O Memory data
SMD14 P2 I/O Memory data
SMD15 P3 I/O Memory data
SMD16 E7 I/O Memory data
SMD17 B5 I/O Memory data
SMD18 C6 I/O Memory data
SMD19 A5 I/O Memory data
SMD20 B6 I/O Memory data
SMD21 C7 I/O Memory data
SMD22 A6 I/O Memory data
SMD23 B7 I/O Memory data
SMD24 N1 I/O Memory data
SMD25 N2 I/O Memory data
SMD26 N4 I/O Memory data
SMD27 N5 I/O Memory data
SMD28 M2 I/O Memory data
SMD29 M3 I/O Memory data
SMD30 L4 I/O Memory data
SMD31 K1 I/O Memory data
