APPENDIX A MIPS III INSTRUCTION SET DETAILS
Preliminary User’s Manual S15543EJ1V0UM
495
ERET
Exception Return
ERET
CO
1
COP0
0 1 0 0 0 0
0
0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
ERET
0 1 1 0 0 0
31
26 25 24
6 5
0
6
1
19
6
Format:
ERET
Description:
ERET is the instruction for returning from an interrupt, exception, or error trap. Unlike a branch or jump instruction,
ERET does not execute the next instruction.
ERET must not itself be placed in a branch delay slot.
If the processor is servicing an error trap (
SR2 = 1), then load the PC from the ErrorEPC register and clear the ERL
bit of the Status register (
SR2). Otherwise (SR2 = 0), load the PC from the EPC register, and clear the EXL bit of
the Status register (
SR1 = 0).
When a MIPS16 instruction can be executed, the value of clearing the least significant bit of the EPC or error EPC
register to 0 is loaded to PC. This means the content of the least significant bit is reflected on the ISA mode bit
(internal).
Operation:
32, 64 T:
if SR
2
= 1 then
if MIPS16EN = 1 then
PC
← ErrorEPC
63..1
|| 0
ISA MODE
← ErrorEPC
0
else
PC
← ErrorEPC
endif
SR
← SR
31..3
|| 0 || SR
1..0
else
if MIPS16EN = 1 then
PC
← EPC
63..1
|| 0
ISA MODE
← EPC
0
else
PC
← EPC
endif
SR
← SR
31..2
|| 0 || SR
0
endif
Exceptions:
Coprocessor unusable exception
