CHAPTER 6 USB CONTROLLER

346

Preliminary User’s Manual S15543EJ1V0UM

Figure 6-14. Receive Descriptor Configuration

-R x B uffer D irectory

B uffer D irectory A ddress

-R x Link P ointer

0

31

0

|

B uffer D esciptor N

B uffer D esciptor 4

B uffer D esciptor 3

B uffer D esciptor 2

B uffer D esciptor 1

B uffer D esciptor 0

Link P ointer

-R x B uffer D escriptor

31

0

16 15

B uffer A ddress

R eserved

S ize

L

1

30

R eserved

29

0

31

0

16 15

30 29

Rx Buffer Directory:

A Rx Buffer Directory. This is composed of buffer descriptors and a link pointer. A single

Rx Buffer Directory can contain up to 255 buffer descriptors.

Rx Buffer Descriptor:

Contains the Rx buffer data.

When Bit31 (Last bit) is set to a ‘1’, that Buffer Descriptor indicates the last buffer in the

pool.

Bit30 is used to discriminate between the Buffer Descriptor and Link Pointer. When set to

1, this bit indicates the Buffer Descriptor.

The "Size" field indicates the buffer size. As the buffer size, a value between 1 and 65535

bytes can be set. The "Buffer Address" field indicates the start address of the buffer.

Rx Link Pointer:

This is the link pointer. It indicates the last Buffer Directory.

Bit31 is set to 0.

Bit30 is used to discriminate between the Buffer Descriptor and Link Pointer. When set to

0, this bit indicates the Link Pointer.

The "Buffer Directory Address" field indicates the start address of the next Buffer

Directory.
