APPENDIX A MIPS III INSTRUCTION SET DETAILS
514 Preliminary User’s Manual S15543EJ1V0UM
LW
Load Word
LW
base
LW
1 0 0 0 1 1
rt offset
31 26 25 21 20 16 15 0
6 5 5 16
Format:
LW rt, offset (base)
Description:
The 16-bit offset is sign-extended and added to the contents of general register base to form a virtual address.
The contents of the word at the memory location specified by the effective address are loaded into general register
rt. In 64-bit mode, the loaded word is sign-extended.
If either of the two least-significant bits of the effective address is non-zero, an address error exception occurs.
Operation:
32 T: vAddr ← ((offset
15
)
16
|| offset
15...0
) + GPR [base]
(pAddr, uncached) ← AddressTranslation (vAddr, DATA)
pAddr
← pAddr
PSIZE - 1...3
|| (pAddr
2...0
xor (ReverseEndian || 0
2
))
mem ← LoadMemory (uncached, WORD, pAddr, vAddr, DATA)
byte
← vAddr
2...0
xor (BigEndianCPU || 0 2 )
GPR [rt] ← mem
31 + 8 * byte...8 * byte
64 T: vAddr
← ((offset
15
)
48
|| offset
15...0
) + GPR [base]
(pAddr, uncached)
← AddressTranslation (vAddr, DATA)
pAddr ← pAddr
PSIZE - 1...3
|| (pAddr
2...0
xor (ReverseEndian || 0 2 ))
mem
← LoadMemory (uncached, WORD, pAddr, vAddr, DATA)
byte ← vAddr
2...0
xor (BigEndianCPU || 0
2
)
GPR [rt]
← (mem
31 + 8 * byte )
32
|| mem 31 + 8 * byte...8 * byte
Exceptions:
TLB refill exception
TLB invalid exception
Bus error exception
Address error exception
