APPENDIX A MIPS III INSTRUCTION SET DETAILS
466
Preliminary User’s Manual S15543EJ1V0UM
CACHE
Cache (2/4)
CACHE
Write back from a cache goes to main memory.
The main memory address to be written is specified by the cache tag and not the physical address translated using
TLB.
TLB Refill and TLB Invalid exceptions can occur on any operation. For Index operations
Note
for addresses in the
unmapped areas, unmapped addresses may be used to avoid TLB exceptions. Index operations never cause a
TLB Modified exception. Bits 17 and 16 of the instruction code specify the cache for which the operation is to be
performed as follows.
Code
Name
Cache
0
I
Instruction cache
1
D
Data cache
2
Reserved
3
Reserved
Note Physical addresses here are used to index the cache, and they do not need to match the cache tag.
Bits 20 to 18 of this instruction specify the contents of cache operaiton. Details are provided from the next page.
