APPENDIX A MIPS III INSTRUCTION SET DETAILS
448
Preliminary User’s Manual S15543EJ1V0UM
BEQ
Branch On Equal
BEQ
rs
BEQ
0 0 0 1 0 0
rt
offset
31
26 25
21 20
16 15
0
6
5
5
16
Format:
BEQ rs, rt, offset
Description:
A branch target address is computed from the sum of the address of the instruction in the delay slot and the 16-bit
offset, shifted left two bits and sign-extended. The contents of general register rs and the contents of general
register
rt are compared. If the two registers are equal, then the program branches to the target address, with a
delay of one instruction.
Operation:
32
T:
target
← (offset
15
)
14
|| offset || 0
2
condition
← (GPR [rs] = GPR [rt])
T+1: if condition then
PC
← PC + target
endif
64
T:
target
← (offset
15
)
46
|| offset || 0
2
condition
← (GPR [rs] = GPR [rt])
T+1: if condition then
PC
← PC + target
endif
Exceptions:
None
