APPENDIX A MIPS III INSTRUCTION SET DETAILS
454
Preliminary User’s Manual S15543EJ1V0UM
BGTZ
Branch On Greater Than Zero
BGTZ
rs
BGTZ
0 0 0 1 1 1
0
0 0 0 0 0
offset
31
26 25
21 20
16 15
0
6
5
5
16
Format:
BGTZ rs, offset
Description:
A branch target address is computed from the sum of the address of the instruction in the delay slot and the 16-bit
offset, shifted left two bits and sign-extended. If the contents of general register rs are zero or greater when
compared to zero, then the program branches to the target address, with a delay of one instruction.
Operation:
32
T:
target
← (offset
15
)
14
|| offset || 0
2
condition
← (GPR [rs]
31
= 0) and (GPR [rs]
≠ 0
32
)
T+1: if condition then
PC
← PC + target
endif
64
T:
target
← (offset
15
)
46
|| offset || 0
2
condition
← (GPR [rs]
63
= 0) and (GPR [rs]
≠ 0
64
)
T+1: if condition then
PC
← PC + target
endif
Exceptions:
None
