APPENDIX A MIPS III INSTRUCTION SET DETAILS

546

Preliminary User’s Manual S15543EJ1V0UM

SH

Store Halfword

SH

base

SH

1 0 1 0 0 1

rt

offset

31

26 25

21 20

16 15

0

6

5

5

16

Format:

SH rt, offset (base)

Description:

The 16-bit

offset is sign-extended and added to the contents of general register base to form an unsigned effective

address. The least-significant halfword of register

rt is stored at the effective address. If the least-significant bit of

the effective address is non-zero, an address error exception occurs.

Operation:

32

T:

vAddr

← ((offset

15

)

16

|| offset

15...0

) + GPR [base]

(pAddr, uncached)

← AddressTranslation (vAddr, DATA)

pAddr

← pAddr

PSIZE - 1...3

|| (pAddr

2...0

xor (ReverseEndian

2

|| 0))

byte

← vAddr

2...0

xor (BigEndianCPU

2

|| 0)

data

← GPR [rt]

63 – 8 * byte...0

|| 0

8 * byte

StoreMemory (uncached, HALFWORD, data, pAddr, vAddr, DATA)

64

T:

vAddr

← ((offset

15

)

48

|| offset

15...0

) + GPR [base]

(pAddr, uncached)

← AddressTranslation (vAddr, DATA)

pAddr

← pAddr

PSIZE - 1...3

|| (pAddr

2...0

xor (ReverseEndian

2

|| 0))

byte

← vAddr

2...0

xor (BigEndianCPU

2

|| 0)

data

← GPR [rt]

63 – 8 * byte...0

|| 0

8 * byte

StoreMemory (uncached, HALFWORD, data, pAddr, vAddr, DATA)

Exceptions:

TLB refill exception

TLB invalid exception

TLB modification exception

Bus error exception

Address error exception
