APPENDIX A MIPS III INSTRUCTION SET DETAILS
480 Preliminary User’s Manual S15543EJ1V0UM
DMFC0
Doubleword Move From System Control Coprocessor
DMFC0
DMF
0 0 0 0 1
COP0
0 1 0 0 0 0
rt rd
31 26 25 21 20 16 15 0
6 5 5 5
0
0 0 0 0 0 0 0 0 0 0 0
11 10
11
Format:
DMFC0 rt, rd
Description:
The contents of coprocessor register rd of the CP0 are loaded into general register rt.
This operation is defined in 64-bit mode or in 32-bit kernel mode. Execution of this instruction in 32-bit user or
supervisor mode causes a reserved instruction exception. All 64-bits of the general register destination are written
from the coprocessor register source. The operation of DMFC0 on a 32-bit coprocessor 0 register is undefined.
Operation:
64 T: data
← CPR [0, rd]
T+1: GPR [rt] ← data
Exceptions:
Coprocessor unusable exception (user mode and supervisor mode if CP0 not enabled)
Reserved instruction exception (32-bit user mode/supervisor mode)
