CHAPTER 3 SYSTEM CONTROLLER
192
Preliminary User’s Manual S15543EJ1V0UM
3.2.4 S_ISR (Interrupt Status Register)
The interrupt status register “S_ISR” is a read-clear and 32-bit word-aligned register. S_ISR indicates the
interruption status from SysAD/IBUS interfaces, timer, UART and so on. If corresponding bit in S_IMR (Interrupt Mask
Register) is set and the interrupt is not masked, system controller interrupts to V
R
4120A using interrupt signal. The bit
in S_ISR is reset after being read by the V
R
4120A. When the same type of incident occurs before the bit has been
read, the bit will be set again. S_ISR is initialized to 0 at reset and contains the following fields:
Bits
Field
R/W
Default
Description
31:18
Reserved
RC
0
Hardwired to 0.
17
MAC2IS
RC
0
MAC2 interrupt:
0 = no MAC2 interrupt pending.
1 = MAC2 interrupt pending.
16
PCIIS
RC
0
PCI interrupt:
0 = no PCI interrupt pending.
1 = PCI interrupt pending.
15:5
Reserved
RC
0
Hardwired to 0.
4
WUIS
RC
0
Wakeup interrupt:
0 = no wakeup request pending.
1 = some wakeup request pending.
3
EXTIS
RC
0
External interrupt:
0 = no external interrupt pending.
1 = external interrupt pending.
2
UARTIS
RC
0
UART interrupt:
0 = no UART interrupt pending.
1 = UART interrupt pending.
UART interruption is one of the following interruptions:
1. UART receive data buffer full interrupt
2. UART transmitter buffer empty interrupt
3. UART line status interrupt
4. UART modem status interrupt
1
TM1IS
RC
0
Timer CH1 interrupt:
0 = no timer CH1 interrupt pending.
1 = timer CH1 interrupt pending.
0
TM0IS
RC
0
Timer CH0 interrupt:
0 = no timer CH0 interrupt pending.
1 = timer CH0 interrupt pending.
Remarks 1. To clear bits 0 to 4 in this register, the V
R
4120A must read the byte that contains the TM0IS register.
In addition, to clear bits 16 to 17, the V
R
4120A must read the byte that contains the PCIIS register.
2. MAC2 interrupt and PCI interrupt can not be masked by system controller.
3. After clearing MAC2IS/PCIIS bit, MAC/PCI block continues to provide interrupt signal to V
R
4120A.
