Preliminary User’s Manual S15543EJ1V0UM 23
CHAPTER 1 INTRODUCTION
The µPD98502 is a high performance controller, which can perform the protocol conversion between IP Packets
and ATM Cells, which is especially suitable for ADSL router. It includes high performance MIPS  based 64-bit RISC
processor V R 4120A CPU core, ATM Cell Processor, Ethernet Controller, USB Controller Block, PCI Controller Block,
UTOPIA2 interface and SDRAM interface.
1.1 Features
• Includes high performance MIPS based 64-bit RISC processor V
R 4120A
• Can perform RTOS and network middleware (M/W) on the chip
• Includes interface for PROM and flash ROM used for storing boot program
• Includes 32-bit RISC controller in ATM Cell Processor
• Software SAR processing by RISC controller affords flexibility for specification update
• Supports CBR/VBR/UBR service classes
• Includes 2-channel 10/100-Mbps Ethernet controller compliant to IEEE802.3, IEEE 802.3u and IEEE802.3x
• Can directly connect external Ethernet PHY device through 3.3 V MII interface
• Includes USB full speed function controller compliant to USB specification 1.1
• Supports operation conforming to the USB Communication Device Class Specification
• Can directly connect 64-Mbit and 128-Mbit SDRAM as external memory
• Includes 32-bit 33-MHz PCI Bus Master compliant to PCI Specification Rev. 2.2
• Includes 8-bit 16.5/25/33-MHz UTOPIA level 2 interface compliant to ATM Forum af-phy-0039
• Includes boundary scan function (JTAG) compliant to IEEE 1149.1
• Includes Micro Wire interface
• Includes 2-ch general purpose timers
• Using advanced CMOS technology
• Power supply 2.5V(Core)/3.3V(I/O)
• Package 500-pin T-BGA
1.2 Ordering Information
Part Number Package
µPD98502N7-H6 500-pin Tape BGA (Heat spread type) (40 Ч 40)
