APPENDIX A MIPS III INSTRUCTION SET DETAILS
Preliminary User’s Manual S15543EJ1V0UM 449
BEQL
Branch On Equal Likely
BEQL
rs
BEQL
0 1 0 1 0 0
rt offset
31 26 25 21 20 16 15 0
6 5 5 16
Format:
BEQL rs, rt, offset
Description:
A branch target address is computed from the sum of the address of the instruction in the delay slot and the 16-bit
offset, shifted left two bits and sign-extended. The contents of general register rs and the contents of general
register rt are compared. If the two registers are equal, the target address is branched to, with a delay of one
instruction. If the conditional branch is not taken, the instruction in the branch delay slot is nullified.
Operation:
32 T: target ← (offset
15 )
14
|| offset || 0
2
condition
← (GPR [rs] = GPR [rt])
T+1: if condition then
PC
← PC + target
else
NullifyCurrentInstruction
endif
64 T: target ← (offset
15
) 46 || offset || 0 2
condition ← (GPR [rs] = GPR [rt])
T+1: if condition then
PC ← PC + target
else
NullifyCurrentInstruction
endif
Exceptions:
None
