APPENDIX A MIPS III INSTRUCTION SET DETAILS
Preliminary User’s Manual S15543EJ1V0UM
529
MFLO
Move From LO
MFLO
0
0 0 0 0 0 0 0 0 0 0
SPECIAL
0 0 0 0 0 0
31
26 25
11 10
16 15
0
6
10
5
6
rd
0
0 0 0 0 0
MFLO
0 1 0 0 1 0
5
6 5
Format:
MFLO rd
Description:
The contents of special register
LO are loaded into general register rd.
To ensure proper operation in the event of interruptions, the two instructions which follow a MFLO instruction may
not be any of the instructions which modify the
LO register: MULT, MULTU, DIV, DIVU, MTLO, DMULT, DMULTU,
DDIV, DDIVU.
Operation:
32, 64 T:
GPR [rd]
← LO
Exceptions:
None
