APPENDIX A MIPS III INSTRUCTION SET DETAILS
Preliminary User’s Manual S15543EJ1V0UM
491
DSRLV
Doubleword Shift Right Logical Variable
DSRLV
rs
SPECIAL
0 0 0 0 0 0
rt
rd
0
0 0 0 0 0
DSRLV
0 1 0 1 1 0
31
26 25
21 20
16 15
11 10
6 5
0
6
5
5
5
5
6
Format:
DSRLV rd, rt, rs
Description:
The contents of general register
rt are shifted right by the number of bits specified by the low-order six bits of
general register
rs, inserting zeros into the high-order bits. The result is placed in register rd.
This operation is defined in 64-bit mode or in 32-bit kernel mode. Execution of this instruction in 32-bit user or
supervisor mode causes a reserved instruction exception.
Operation:
64
T:
s
← GPR [rs]
5..0
GPR [rd]
← 0
s
|| GPR [rt]
63..s
Exceptions:
Reserved instruction exception (32-bit user mode/supervisor mode)
