APPENDIX A MIPS III INSTRUCTION SET DETAILS
Preliminary User’s Manual S15543EJ1V0UM 561
SW
Store Word
SW
base
SW
1 0 1 0 1 1
rt offset
31 26 25 21 20 16 15 0
6 5 5 16
Format:
SW rt, offset (base)
Description:
The 16-bit offset is sign-extended and added to the contents of general register base to form a virtual address.
The contents of general register rt are stored at the memory location specified by the effective address.
If either of the two least-significant bits of the effective address are non-zero, an address error exception occurs.
Operation:
32 T: vAddr ← ((offset
15
)
16
|| offset
15...0
) + GPR [base]
(pAddr, uncached) ← AddressTranslation (vAddr, DATA)
pAddr ← pAddr
PSIZE - 1...3
|| (pAddr
2...0
xor (ReverseEndian || 0
2
))
byte ← vAddr
2...0
xor (BigEndianCPU || 0 2 )
data ← GPR [rt]
63 – 8 * byte || 0
8 * byte
StoreMemory (uncached, WORD, data, pAddr, vAddr, DATA)
64 T: vAddr ← ((offset
15
) 48 || offset
15...0
) + GPR [base]
(pAddr, uncached)
← AddressTranslation (vAddr, DATA)
pAddr ← pAddr
PSIZE - 1...3
|| (pAddr
2...0
xor (ReverseEndian || 0 2 ))
byte
← vAddr
2...0
xor (BigEndianCPU || 0
2
)
data ← GPR [rt]
63 – 8 * byte || 0
8 * byte
StoreMemory (uncached, WORD, data, pAddr, vAddr, DATA)
Exceptions:
TLB refill exception
TLB invalid exception
TLB modification exception
Bus error exception
Address error exception
