2.4.2.6 Supervisor-mode virtual addressing

Supervisor mode shown in Figure 2-29 is designed for layered operating systems in which a true kernel runs in

Kernel mode, and the rest of the operating system runs in Supervisor mode.

The processor operates in Supervisor mode when the Status register contains the following bit-values:

— KSU = 01
— EXL = 0
— ERL = 0

In conjunction with these bits, the SX bit in the Status register selects Supervisor mode addressing:

— When SX = 0: 32-bit supervisor space is selected.
— When SX = 1: 64-bit supervisor space is selected.

Figure 2-29 shows the supervisor mode address mapping, and Table 2-28 lists the characteristics of the

Supervisor mode segments.

Figure 2-29. Supervisor Mode Address Space

64-bit mode

32-bit mode

Note

DFFF_FFFFH

E000_0000H

C000_0000H

FFFF_FFFFH

Address error

FFFF_FFFF_FFFF_FFFFH

suseg

sseg

7FFF_FFFFH

0000_0000H

8000_0000H

xsuseg

xsseg

csseg

BFFF_FFFFH

4000_00FF_FFFF_FFFFH

4000_0100_0000_0000H

0.5 Gbytes with

TLB mapping

Address error

2 Gbytes with TLB

mapping

Address error

0.5 Gbytes with

TLB mapping

Address error

1 Tbyte with TLB

mapping

Address error

1 Tbyte with TLB

mapping

FFFF_FFFF_E000_0000H

FFFF_FFFF_DFFF_FFFFH

FFFF_FFFF_C000_0000H

FFFF_FFFF_BFFF_FFFFH

3FFF_FFFF_FFFF_FFFFH

4000_0000_0000_0000H

0000_0000_0000_0000H

0000_00FF_FFFF_FFFFH

0000_0100_0000_0000H

Note

The V

R

4120A uses 64-bit addresses within it. For 32-bit mode addressing, bit 31 is sign-extended to bits

32 to 63, and the resulting 32 bits are used for addressing. Usually, it is impossible for 32-bit mode
programs to generate invalid addresses. In an operation of base register + offset for addressing, however,
a two's complement overflow may occur, causing an invalid address. Note that the result becomes
undefined. Two factors that can cause a two’s complement follow:

— When offset bit 15 is 0, base register bit 31 is 0, and bit 31 of the operation “base register + offset” is 1
— When offset bit 15 is 1, base register bit 31 is 1, and bit 31 of the operation “base register + offset” is 0
