APPENDIX A MIPS III INSTRUCTION SET DETAILS
Preliminary User’s Manual S15543EJ1V0UM
453
BGEZL
Branch On Greater Than Or Equal To Zero Likely
BGEZL
rs
REGIMM
0 0 0 0 0 1
BGEZL
0 0 0 1 1
offset
31
26 25
21 20
16 15
0
6
5
5
16
Format:
BGEZL rs, offset
Description:
A branch target address is computed from the sum of the address of the instruction in the delay slot and the 16-bit
offset, shifted left two bits and sign-extended. If the contents of general register rs are zero or greater when
compared to zero, then the program branches to the target address, with a delay of one instruction. If the
conditional branch is not taken, the instruction in the branch delay slot is nullified.
Operation:
32
T:
target
← (offset
15
)
14
|| offset || 0
2
condition
← (GPR [rs]
31
= 0)
T+1: if condition then
PC
← PC + target
else
NullifyCurrentInstruction
endif
64
T:
target
← (offset
15
)
46
|| offset || 0
2
condition
← (GPR [rs]
63
= 0)
T+1: if condition then
PC
← PC + target
else
NullifyCurrentInstruction
endif
Exceptions:
None
