APPENDIX A MIPS III INSTRUCTION SET DETAILS
486
Preliminary User’s Manual S15543EJ1V0UM
DSLL32
Doubleword Shift Left Logical + 32
DSLL32
0
0 0 0 0 0
SPECIAL
0 0 0 0 0 0
rt
rd
sa
DSLL32
1 1 1 1 0 0
31
26 25
21 20
16 15
11 10
6 5
0
6
5
5
5
5
6
Format:
DSLL32 rd, rt, sa
Description:
The contents of general register
rt are shifted left by 32 + sa bits, inserting zeros into the low-order bits. The result
is placed in register
rd.
This operation is defined in 64-bit mode or in 32-bit kernel mode. Execution of this instruction in 32-bit user or
supervisor mode causes a reserved instruction exception.
Operation:
64
T:
s
← 1 || sa
GPR [rd]
← GPR [rt]
(63 - s)..0
|| 0
s
Exceptions:
Reserved instruction exception (32-bit user mode/supervisor mode)
