CHAPTER 6 USB CONTROLLER

Preliminary User’s Manual S15543EJ1V0UM

365

The V

R

4120A is not permitted to write to other than USB Controller's USB General Mode Register and USB

Interrupt Mask Register 2 while USB Controller is in the Suspend status. Otherwise, after USB Controller enters the

Resume status, its operation will be unpredictable.

6.7.2 Resume

The Resume sequence is shown below.

Figure 6-28. Resume Sequence

V

R

4120A

U S B

C ontroller

S tarts R esum e

S ignaling

(1)

20 m s

M ore than 20 m s

progress,stops

R esum e S ignaling

and executes

E O P S ignaling

for 2 bit-tim e

S ets U R S M bit in

U S B G eneral

S tatus R egister 2

to a '1', and

issues the

interruption to

V

R

4120A .

R eceives U S B

interruption, reads

status register.

D etects transit to

R esum e state.

H ost P C

D etects R esum e

S ignaling, transits

to R esum e state.

E nds of R esum e

processing

(2)

(3)

(4)

(5)

(6)

µ

P D 98502

(1) The Host PC starts Resume Signaling. The Resume Signaling is passed to every device connected to the

USB.

(2) After at least 20 ms have elapsed, the Host PC stops the Resume Signaling then performs EOP Signaling for a

2bit-time duration.

(3) This causes the Host PC to terminate its Resume processing.

(4) USB Controller receives the Resume Signaling.

(5) USB Controller sets the URSM bit (Bit 18) of the USB General Status Register 2 (Address: 1000_1018H) to a

‘1’, then issues an interruption to the V

R

4120A. If clock supplement is stopped, V

R

4120A has to check

“usbwakeup_p” signal instead of “URSM” bit.

(6) The V

R

4120A receives the interruption from USB Controller and, as a result, determines that the USB has

entered the Resume status.

After USB Controller enters the Resume status, it continues with the transmit/receive processing it was performing

immediately before it entered the Suspend status.
