APPENDIX A MIPS III INSTRUCTION SET DETAILS

Preliminary User’s Manual S15543EJ1V0UM

473

DDIV

Doubleword Divide

DDIV

SPECIAL

0 0 0 0 0 0

0 0 0 0 0 0 0 0 0 0

DDIV

0 1 1 1 1 0

26 25

21 20

16 15

6 5

Format:

DDIV rs, rt

Description:

The contents of general register

rs are divided by the contents of general register rt, treating both operands as 2’s

complement values. No overflow exception occurs under any circumstances, and the result of this operation is

undefined when the divisor is zero.

This instruction is typically followed by additional instructions to check for a zero divisor and for overflow.

When the operation completes, the quotient word of the double result is loaded into special register

LO, and the

remainder word of the double result is loaded into special register

HI.

If either of the two preceding instructions is MFHI or MFLO, the results of those instructions are undefined. Correct

operation requires separating reads of

HI or LO from writes by two or more instructions.

This operation is defined in 64-bit mode or in 32-bit kernel mode. Execution of this instruction in 32-bit user or

supervisor mode causes a reserved instruction exception.

Operation:

T-2:

← undefined

T-1:

← undefined

← GPR [rs] div GPR [rt]

← GPR [rs] mod GPR [rt]

Exceptions:

Reserved instruction exception (32-bit user mode/supervisor mode)
