1-4 MPC8260 PowerQUICC II UserÕs Manual MOTOROLA
Part I. Overview
Ñ Two serial management controllers (SMCs), identical to those of the MPC860
Ð Provide management for BRI devices as general-circuit interface (GCI)
controllers in time- division-multiplexed (TDM) channels
Ð Transparent
Ð UART (low-speed operation)
Ñ One serial peripheral interface identical to the MPC860 SPI
Ñ One I
2
C controller (identical to the MPC860 I
2
C controller)
Ð Microwire compatible
Ð Multiple-master, single-master, and slave modes
Ñ Up to eight TDM interfaces
Ð Supports two groups of four TDM channels for a total of eight TDMs
Ð 2,048 bytes of SI RAM
Ð Bit or byte resolution
Ð Independent transmit and receive routing, frame synchronization.
Ð Supports T1, CEPT, T1/E1, T3/E3, pulse code modulation highway, ISDN
basic rate, ISDN primary rate, Motorola interchip digital link (IDL), general
circuit interface (GCI), and user-deÞned TDM serial interfaces
Ñ Eight independent baud rate generators and 20 input clock pins for supplying
clocks to FCC, SCC, and SMC serial channels
Ñ Four independent 16-bit timers that can be interconnected as two 32-bit timers
1.2 MPC8260Õs Architecture Overview
The MPC8260 has two external buses to accommodate bandwidth requirements from the
high-speed system core and the very fast communications channels. As shown in
Figure 1-1, the MPC8260 has three major functional blocks:
¥ A 64-bit PowerPC core derived from the MPC603e with MMUs and cache
¥ A system interface unit (SIU)
¥ A communications processor module (CPM)
