MOTOROLA Chapter 12. IEEE 1149.1 Test Access Port 12-17
Part III. The Hardware Interface
425 i.obs a[8] io Ñ
426 o.pin a[8] io g109.ctl
427 i.obs a[7] io Ñ
428 o.pin a[7] io g108.ctl
429 i.obs a[6] io Ñ
430 o.pin a[6] io g108.ctl
431 i.obs a[5] io Ñ
432 o.pin a[5] io g108.ctl
433 i.obs a[4] io Ñ
434 o.pin a[4] io g108.ctl
435 i.obs a[3] io Ñ
436 o.pin a[3] io g108.ctl
437 IO.ctl g108.ctl С С
438 i.obs a[2] io Ñ
439 o.pin a[2] io g108.ctl
440 i.obs a[1] io Ñ
441 o.pin a[1] io g108.ctl
442 i.obs a[0] io Ñ
443 o.pin a[0] io g108.ctl
444 i.obs tt[3] io Ñ
445 o.pin tt[3] io g112.ctl
446 i.obs tt[2] io Ñ
447 o.pin tt[2] io g112.ctl
448 IO.ctl g112.ctl С С
449 i.obs tt[1] io Ñ
450 o.pin tt[1] io g112.ctl
451 i.obs tt[0] io Ñ
452 o.pin tt[0] io g112.ctl
453 i.obs tt[4] io Ñ
454 o.pin tt[4] io g112.ctl
455 i.obs artry_b io Ñ
456 o.pin artry_b io g118.ctl
457 IO.ctl g118.ctl С С
458 i.obs aack_b io Ñ
459 o.pin aack_b io g117.ctl
460 IO.ctl g117.ctl С С
461 i.obs abb_b_irq2_b io Ñ
462 o.pin abb_b_irq2_b io g116.ctl
463 IO.ctl g116.ctl С С
Table 12-2. Boundary Scan Bit Definition (Continued)
Bit Cell Type Pin/Cell Name Pin Type Output Control Cell
