The SIVEC can be read as either a byte, half word, or a word. When read as a byte, a branch
table can be used in which each entry contains one instruction (branch). When read as a half
word, each entry can contain a full routine of up to 256 instructions. The interrupt code is
deÞned such that its two lsbs are zeroes, allowing indexing into the table, as shown in
Figure 4-19.

Figure 4-19. Interrupt Table Handling Example

Note that the MPC8260 differs from previous MPC8xx implementations in that when an
interrupt request occurs, SIVEC can be read. If there are multiple interrupt sources, SIVEC
latches the highest priority interrupt. Note that the value of SIVEC cannot change while it
is being read.

4.3.1.7 SIU External Interrupt Control Register (SIEXR)

Each deÞned bit in the SIU external interrupt control register (SIEXR), shown in
Figure 4-20, determines whether the corresponding port C line asserts an interrupt request
upon either a high-to-low change or any change on the pin. External interrupts can come
from port C (PC[0-15]).

BASE

b Routine1

b Routine2

b Routine3

b Routine4

•

BASE + n

BASE + 4

BASE + 8

BASE + C

BASE +10

BASE

1st Instruction of Routine1

1st Instruction of Routine2

1st Instruction of Routine3

1st Instruction of Routine4

•

BASE + n

BASE + 400

BASE + 800

BASE + C00

BASE +1000

•

INTR: ¥ ¥ ¥

Save state

R3 <- @ SIVEC

R4 <-- Base of branch table

¥ ¥ ¥

lbz

add

mtspr

bctr

RX, R3 (0)

# load as byte

RX, RX, R4

CTR, RX
