3-14 MPC8260 PowerQUICC II UserÕs Manual MOTOROLA
Part I. Overview
MCC2 Registers
11B50 MCCE2 MCC2 event register 16 bits 27.10.1/27-18
11B54 MCCM2 MCC2 mask register 16 bits
11B58 MCCF2 MCC2 conÞguration register 8 bits 27.8/27-15
11B59Ð11FFF Reserved Ñ 1,159
bytes Ñ
SI1 RAM
12000Ð121FF SI1TxRAM SI 1 transmit routing RAM 512 14.4.3/14-10
12200Ð123FF Reserved 512
12400Ð125FF SI1RxRAM SI 1 receive routing RAM 512 14.4.3/14-10
12600Ð127FF Reserved 512
SI2 RAM
12800Ð129FF SI2TxRAM SI 2 transmit routing RAM 512 14.4.3/14-10
12A00Ð12BFF Reserved С 512 С
12C00Ð12DFF SI2RxRAM SI 2 receive routing RAM 512 14.4.3/14-10
12E00Ð12FFF Reserved С 512 С
13000Р137FF Reserved Reserved 2048 С
13800Р13FFF Reserved Reserved 2048 Ñ
Table 3-1. Internal Memory Map (Continued)
Internal
Address
Abbreviation Name Size Section/Page Number
