■ KI (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
■ KD (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
■ TD (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
■ LOOP GAIN (Visible when LSM-2020 is enabled and OUTPUT TYPE = ANALOG.)
■ DROOP
■ DROOP GAIN
■ RAMP RATE (Visible when LSM-2020 is enabled.)
■ BASELOAD LVL (Visible when LSM-2020 is enabled.)
■ BL LV SRC (Visible when LSM-2020 is enabled.)
■ PF SRC (Visible when LSM-2020 is enabled.)
■ BL ALG MAX (Visible when LSM-2020 is enabled.)
■ BL ALG MIN (Visible when LSM-2020 is enabled.)
■ BRKR OPEN PT (Visible when LSM-2020 is enabled.)
● CONTROL DEBUG (Visible when LSM-2020 is enabled.)
○ kW RAMP
○ kW RAMP DMD
○ WATT DEMAND
○ SPEED PID
○ kW PID
○ SPEED ERR
○ kW ERR
○ SPEED BIAS
○ PF SETPT
○ kvar RAMP
○ var RAMP DMD
○ var DEMAND
○ VOLT PID
○ kvar PID
○ VOLT ERR
○ kvar ERR
○ VOLT BIAS
MULTIGEN MANAGEMENT (Visible when LSM-2020 is enabled.)
● AVR ANALOG OUTPUT
○ OUTPUT TYPE
○ MIN OUTPUT
○ MAX OUTPUT
○ VOLT RESPONSE
● GOV ANALOG OUTPUT
○ OUTPUT TYPE
○ MIN OUTPUT
○ MAX OUTPUT
○ SPD RESPONSE
● LOAD SHARE LINE
○ MIN VOLTAGE
○ MAX VOLTAGE
● DEMAND START STOP
○ ENABLE
○ START TD 1
○ START TD 2
○ STOP TD
○ START LVL 1
○ START LVL 2
○ STOP LVL
● SEQUENCING
○ SEQUENCE ID
○ MODE
○ MAX GEN START
○ MAX GEN STOP
○ LAST UNIT SHUTDN
● NETWORK CONFIG
○ EXP SEQ ID X (X = 1 TO 16)
