Basler Electric DGC-2020 User Manual
Page 528
B-96
DGC-2020 Modbus
™ Communication
9400200990 Rev X
Register
Description
Type
Units
Scaling
Factor
R/W
Range
46086
J1939-ADEC Transistor
Out Bit Field
Uint32
Bit Packed Data
N/A
R
0 - 4294967295
46088
J1939-ADEC L1L ECU
Power Supply Volts
Uint32
0.001 V/bit
N/A
R
0 - 4294967.295
46090
J1939-ADEC L2L ECU
Power Supply Volts
Uint32
0.001 V/bit
N/A
R
0 - 4294967.295
46092
J939-ADEC U1LECU
Power Supply Volts
Uint32
0.001 V/bit
N/A
R
0 - 4294967.295
46094
J1939-ADEC U2L ECU
Power Supply Volts
Uint32
0.001 V/bit
N/A
R
0 - 4294967295
46096
J1939-ADEC Trip Idle
Time
Uint32
1 sec per bit, 0
offset
N/A
R
0 - 4294967295 sec
46098
J1939-ADEC T Coolant
Limit Hi
Uint32
0.01 Deg C/Bit, 0
offset
N/A
R
0 - 42949672.95
46100
J1939-ADEC T Coolant
Limit Hi Hi
Uint32
0.01 Deg C/Bit, 0
offset
N/A
R
0 - 42949672.95
46102
J1939-ADEC T Charge
Air Limit Hi
Uint32
0.01 Deg C/Bit, 0
offset
N/A
R
0 - 42949672.95
46104
J1939-ADEC T
Intercooler Limit Hi
Uint32
0.01 Deg C/Bit, 0
offset
N/A
R
0 - 42949672.95
46106
J1939-MTU Sps Node
Uint32
No Scale or Offset
N/A
R
0 - 255
46108
J1939-MTU Sw Type
Uint32
No Scale or Offset
N/A
R
0 - 255
46110
J1939-MTU Sw Var
Uint32
No Scale or Offset
N/A
R
0 - 255
46112
J1939-MTU Sw Ed 1
Uint32
No Scale or Offset
N/A
R
0 - 255
46114
J1939-MTU Sw Ed2
Uint32
No Scale or Offset
N/A
R
0 - 255
46116
J1939-MTU Rev
Uint32
No Scale or Offset
N/A
R
0 - 255
46118
J1939-MTU Sw Mod
Uint32
No Scale or Offset
N/A
R
0 - 255
46120
J1939-ECU Protect
Lamp Status Data
Uint32
Raw ECU
Parameter Data
N/A
R
0 = Off
1 = On
2 = Slow Flash
3 = Fast Flash
46122
J1939-ECU Warning
Lamp Status Data
Uint32
Raw ECU
Parameter Data
N/A
R
0 = Off
1 = On
2 = Slow Flash
3 = Fast Flash
46124
J1939-ECU Red Stop
Lamp Status Data
Uint32
Raw ECU
Parameter Data
N/A
R
0 = Off
1 = On
2 = Slow Flash
3 = Fast Flash
46126
J1939-ECU Malfunction
Status Data
Uint32
Raw ECU
Parameter Data
N/A
R
0 = Off
1 = On
2 = Slow Flash
3 = Fast Flash
46128-
248
RESERVED
46250
PLC Timer 1 Seconds
Int32
Second
Deci
RW
0 - 18000
46252
PLC Timer 2 Seconds
Int32
Second
Deci
RW
0 - 18000
46254
PLC Timer 3 Seconds
Int32
Second
Deci
RW
0 - 18000
46256
PLC Timer 4 Seconds
Int32
Second
Deci
RW
0 - 18000
46258
PLC Timer 5 Seconds
Int32
Second
Deci
RW
0 - 18000
46260
PLC Timer 6 Seconds
Int32
Second
Deci
RW
0 - 18000
