Chapter 5 The Environment 231
Delay Line Parameters
The Delay Object has the following parameters:
Thru Original
If this box is checked, the original signal is passed thru. If unchecked, the original signal
is suppressed.
Repeats
Number of event repeats (1 to 99). Setting 0 = delay switched off.
Del
The delay time between the individual repeats. The left value is in divisions, and the
right value in ticks.
Trp
The transposition of note events per repeat (±99 semitones).
Vel
The change in the velocity values of note events per repeat (±99).
Voice Limiter Object
The voice limiter restricts the number of MIDI notes (1 to 32) that can be held
simultaneously.
It does this by “note stealing”—newly arriving notes will cause (some of the) currently
held notes to be turned off, once the voice limit is reached (see the Priority parameter
below).
To create a new voice limiter, select New > Voice Limiter.
Normally, you will assign the voice limiter to an Arrange track, and cable its output to
the instrument Object that you want to voice limit. Alternately, you could cable it
between an instrument Object (breaking its internal port connection) and a port
Object.
Voice Limiter Parameters
Voices
This parameter defines the maximum number of voices that be simultaneously played.
It ranges from 1 to 32.
Priority
This is where you define which notes are stolen (are turned off ) when the number of
held notes exceeds the limit.
