173
Step Command Remarks
1. Enter system view. system-view N/A
2. Enter DHCP address pool view.
dhcp server ip-pool pool-name
[ extended ]
N/A
3. Specify the IP address of the
primary network calling
processor.
voice-config ncp-ip ip-address Not specified by default.
4. Specify the IP address of the
backup network calling
processor.
voice-config as-ip ip-address
Optional.
Not specified by default.
5. Configure the voice VLAN.
voice-config voice-vlan vlan-id
{ disable | enable } Optional.
Not configured by default.
6. Specify the failover IP address
and dialer string. voice-config fail-over
ip-address dialer-string
Optional.
No failover IP address or dialer
string is specified by default.
NOTE:
Specify an IP address for the network calling processor before performing other configurations.
Configuring the TFTP server and bootfile name for the client
For the DHCP server to support client auto-configuration, you must specify the IP address or name of a
TFTP server and the bootfile name in the DHCP address pool. You do not need to perform any
configuration on the DHCP client.
The DHCP client uses these parameters to contact the TFTP server and request the configuration file used
for system initialization.
1. When a router starts up without loading any configuration file, the system sets an active interface
(such as the interface of the default VLAN or a Layer 3 Ethernet interface) as the DHCP client to
request from the DHCP server for parameters, such as an IP address and name of a TFTP server,
and the bootfile name.
2. After getting related parameters, the DHCP client will send a TFTP request to obtain the
configuration file from the specified TFTP server for system initialization. If the client cannot get
such parameters, it will perform system initialization without loading any configuration file.
When Option 55 in the client's request contains parameters of Option 66, Option 67, or Option 150, the
DHCP server will return the IP address or name of the specified TFTP server, and bootfile name to the
client.
To configure the IP address and name of the TFTP server and the bootfile name in the DHCP address
pool:
Step Command Remarks
1. Enter system view. system-view N/A
2. Enter DHCP address pool
view. dhcp server ip-pool pool-name
[ extended ]
N/A
3. Specify the TFTP server. tftp-server ip-address ip-address
Use either command.
Not specified by default.
4. Specify the name of the TFTP
server.
tftp-server domain-name domain-name
