550

Network OS NETCONF Operations Guide

53-1003231-02

Configuring a multigroup virtual router cluster

35

Configuring Router 2 as master for second virtual router group

The following example RPC configures Router2 as the master for the second router
group. Ensure that VCS Fabric mode is enabled, and then perform the following steps.

1. Establish a NETCONF session with Router 2.

2. To configure the Ethernet interface link for Router 2, enable configuration of VE interface 15.

3. Assign Router 2 to group 2.

4. Configure Ethernet port 3/2 as the tracking port for VE interface 15, with a track priority of 20.

VE interface 15 will have its priority reduced to 20 should port 3/2 fail.

5. Configure 192.53.5.253 as the virtual IP address for group 2.

NOTE

(For VRRP-E only) The virtual IP address cannot be the same as a real IP address configured on
the interface.

6. To establish Router 2 as the master, set the priority to 110; that is, a higher value than the

default value of 100.

102

15

2

192.53.5.253

tengigabitethernet

3/2

20

110
