Network OS NETCONF Operations Guide

437

53-1003231-02

Queueing

29

2. Return a list of interfaces that are bound to a DSCP-to-CoS map using an xpath filter.

You must use an xpath filter and not a subtree filter in this case, because the element to be
used for the selection criteria (name) resides at a lower level in the
hierarchy than the information to be retrieved (the interface name).

The following example returns the interface names to which the DSCP-to-CoS map named
“test” is bound. In this case, the map named “test” is bound to interfaces 0/59 and 0/60.

select="/interface/tengigabitethernet/qos[dscp-cos='test']">

xmlns="urn:ietf:params:xml:ns:netconf:base:1.0" message-id="2317">

0/59

0

test

0/60

0

test

Traffic class mapping

The Brocade switch supports eight unicast traffic classes for isolation and to control servicing for
different priorities of application data. Traffic classes are numbered from 0 through 7, with higher
values designating higher priority.

Refer to the Network OS Administrator’s Guide for an explanation of default user-priority to traffic
class mappings for unicast traffic and for multicast traffic.

Mapping CoS-to-Traffic-Class

NOTE

Creating a CoS-to-Traffic-Class map is available only in standalone mode.
