128

Network OS NETCONF Operations Guide

53-1003231-02

Zone configuration scenario

10

NOTE

This operation adds to the defined configuration. It does not replace the defined configuration.

To add a saved configuration to the running configuration, issue the RPC and set
the input elements as follows:

In the element, specify the location of the saved configuration you want to restore.

In the element, specify “running-config”.

https://[email protected]:passphrase/cfg/archiveMay7.txt

running-config

6

in-progress

Zone configuration scenario

FIGURE 3

Zone configuration example

Private Storage

WWN 50:05:07:61:00:09:20:b4

Private Storage

WWN 50:05:07:61:00:22:18:9b

Shared Storage

WWN 50:05:07:61:00:1b:62:ed

Host 1

WWN 20:00:00:05:1e:ed:95:38

Host 2

WWN 20:00:00:05:1e:ed:18:c3

Zone A

Zone B
