VRRP basic configuration example
35
Configuring the backup router
To create a basic backup router configuration for Router 2 in Figure 8 on page 534, perform the
following steps.
1. Establish a NETCONF session with Router 2.
2. Issue the RPC to edit the running configuration.
3. Ensure that VCS Fabric mode is enabled on Router 2.
true
4. Globally enable VRRP and VRRP-E for the local routing bridge (Router 2).
NOTE
The leaf element enables both VRRP and VRRP-E globally.
5. Configure the tengigabitethernet interface link for Router 2.
102/1/5
6. Configure the IP address of the Ethernet link interface for Router 2.
xmlns="urn:brocade.com:mgmt:brocade-ip-config">
This router will become the backup router to Router 1.
