Access Navigator - Release 1.8 August 2003 5-17
Physical Installation
Attach Access Navigator to Plywood
Attach Access Navigator to Plywood
1. Position Access Navigator with brackets attached over screw hole locations marked in plywood (see
Figure 5-12 on page 5-20 ).
2. Secure mounting brackets to plywood using eight #8 × 3/4 inch panhead screws (see D in Figure
5-13 on page 5-21 ).
WARNING! I F A CCESS N AVIGATOR IS MOUNTED ON PLYWOOD , DO NOT USE A
HAMMER TO ATTACH PLYWOOD TO WALL BECAUSE THE IMPACT SHOCK MAY DAMAGE
THE A CCESS N AVIGATOR AND OTHER COMPONENTS MOUNTED ON THE PLYWOOD . A
POWER DRILL AND SCREWDRIVER IS RECOMMENDED TO AVOID DAMAGE .
3. Attach plywood to wall using fasteners appropriate for heavy objects.
