Access Navigator - Release 1.8 August 2003 18-143
CLI Language Reference
CLI Command List
Show DS1 All
Purpose: This command provides an abbreviated list of showing the DS1 settings and current
service status for all 32 DS1 circuits. It produces a message similar to the following,
showing the circuit identifier, DS1 number, current status (up/down), and some
common parameters of interest in trouble-shooting. (To obtain a detailed list for a
specific DS1 or range of DS1s, use the show ds1 command.)
Security: Level 3 (monitor)
Syntax: show ds1 all
Message:
Remote
Line Term Device
Circuit ID Link Type Code Framing ID FDL Mgmt
---------- ---- ------ ---- ------- ---- ----- ------
CA DS1# 01 UP DROP B8ZS ESF None CA IP
CA DS1# 02 DOWN DROP B8ZS ESF None None
CA DS1# 03 DOWN DROP B8ZS ESF None None
CA DS1# 04 DOWN DROP B8ZS ESF None None
CA DS1# 05 DOWN DROP B8ZS ESF None None
CA DS1# 06 DOWN DROP B8ZS ESF None None
CA DS1# 07 DOWN DROP B8ZS ESF None None
CA DS1# 08 DOWN DROP B8ZS ESF None None
CA DS1# 09 DOWN DROP B8ZS ESF None None
CA DS1# 10 DOWN DROP B8ZS ESF None None
CA DS1# 11 DOWN DROP B8ZS ESF None None
CA DS1# 12 DOWN DROP B8ZS ESF None None
CA DS1# 13 DOWN DROP B8ZS ESF None None
CA DS1# 14 DOWN DROP B8ZS ESF None None
CA DS1# 15 DOWN DROP B8ZS ESF None None
CA DS1# 16 DOWN DROP B8ZS ESF None None
CA DS1# 17 DOWN DROP B8ZS ESF None None
CA DS1# 18 DOWN DROP B8ZS ESF None None
degraded minutes (DM) The total number of minutes in which the estimated error
rate exceeds 1E-6 but does not exceed 1E-3. Degraded Minutes
are determined by collecting all of the Available Seconds,
removing any Severely Errored Seconds, grouping the result in
60-second long groups, and counting a 60-second long group
(one minute) as degraded if the cumulative errors during the
seconds present in the group exceed 1E-6. Available seconds are
merely those seconds that are not Unavailable (UAS).
linecode violations (LCV or CV) The total number of line code violations that have
been detected during the measurement interval. An LCV is the
occurrence of a Bi-polar Violation (BPV) or Excessive Zeros.
Performance
Thresholds Description
