Physical
Installation
Attach Access Navigator to Plywood
Figure 5-11. Plywood Sheet, Minimum Size
Plywood Sheet
Wall View
End View
21 inches
(Minimum)
10 inches
(Minimum)
Plywood Sheet
3/4 inch thick
(Minimum)
UP
Wire Tie
Wire Tie
