Page 417: Overview
Access Navigator - Release 1.8
August 2003
16-19
Maintenance
Procedures
Replace Quad T1 Framer Card
Replace Quad T1 Framer Card
Procedure Summary
n
n
n
n
n
Determine Which Replacement Procedure to Use
n
Replace Protected Controller Card
n
Replace Unprotected Controller Card
Overview
This procedure provides steps for replacing a Quad T1 Framer (QF) card. The Access Navigator
can hold up to eight QF cards, providing a total of 32 DS1 circuits. QF cards are hot-swappable and
can be installed at any time, without interrupting service on other cards, except when the card is
providing a DS1 clock source used for system timing.
Each Quad T1 Framer card contains four DS1 circuits. DS1 circuit numbers are determined by the
QF card slot (see also Figure 16-10):
QF Card Slot
DS1 Circuit Numbers
#1
1
2
3
4
#2
5
6
7
8
#3
9
10
11
12
#4
13
14
15
16
#5
17
18
19
20
#6
21
22
23
24
#7
25
26
27
28
#8
29
30
31
32
