FDL Interface
Access Bank II Capabilities
RS-232 interface Asynchronous RS-232 port for subrate data
connection between two Access Bank II terminals
Assignable to one DS0
Baud rate: 1200, 2400, 4800, 9600, 19200, 38400,
57600
Data bits: 7, 8
Start bits: 0
Stop bits: 1, 2
Parity: None, Even, Odd
Receive clock: Internal, External
Loopback: line
SDSL interface High-speed data port for SDSL router
Data rates up to 1.024 Mbps
Assignable to a group of up to 16 DS0s
SDSL port replaces T1 #2 port on Access Bank II/
SDSL
T1 Drop interface (T1 #1 or #2) Drop and insert port for T1 PBX
High-speed data port for T1 router
Assignable to a group of one or more DS0s
DS0s on T1 drop are assigned sequentially, starting
with DS0 #1
Framing: D4 (SF), ESF
Line code: AMI, B8ZS
Line build out: 0 to 666 feet, 0 to –22.5 dB
Loopback: line, payload
V.35 interface High-speed data port for network router connection
Assignable to a group of one or more DS0s
Data speed (Kbps): Nx56 or Nx64, where N is the
number of DS0s assigned
CTS: Force High, Force Low, Follow CD, Follow
RTS
Rx timing: Internal, External
Clock inversion: None, Rx, Tx, Rx and Tx
Data inversion: None, Invert
V.54 Data Service Unit (DSU) loopcode detection:
on, off
Access Bank II Capabilities (Continued)
Interface Capabilities and Settings
