Access Navigator - Release 1.8
August 2003
6-25
Electrical
Installation
External Timing Source (BITS) Connection
External Timing Source (BITS) Connection
The Access Navigator has a Timing Input connector for use with an external timing source, such as a
Building Integrated Timing Supply (BITS), to synchronize wireline transmissions.
Installation Summary
n
n
n
Tools and Materials
Obtain the following tools and materials:
•
ANSI T1.403 RJ48C timing input cable, or materials to make timing cable (see Step 2)
•
Continuity tester
